PU Sandwich Panel Line
Description:
Continuous PU sandwich panel Line is name of the production line. PU sandwich compound panel is a new kind of green-color building material. It is widely used on wall panel, partition pane, garage door, cold storage door, duct panels and the roof building of the industrial factory and so on. It is also used in the overseas civil house construction.
Customers prefer the PU insulated compound panel, because of its available fire- proof, panel color and panel profile. It becomes more and more popular among all new types of building materials.
Total components of the Continuous Polyurethane (PU) Sandwich panel line:
Roll forming machines PU foam sprayer machine
Double belt pressing machine
Cross saw cutting machine
Control cabinet
Components of the Continuous Polyurethane (PU) Sandwich panel Line:
Roll forming machine
Top panel roll forming machine system
10T hydraulic decoiler with coil car 1 set bottom panel forming machine system
Combination machine 1 set
Film covering machine 1 set
Slitting machine side waster recoiling machine 1 set
Hydraulic flying pre-cut system (flying shear) 1 set
Top panel forming machine 2 sets
Top panel: adjustable by the straight rail, 3 ribs forming rollers stations, 15 roller stations
Top wall panel: adjustable by the straight rail, 3 ribs forming rollers stations, 15 roller stations
Steel frame platform 1 set
Straight rails and horizontal move and driver system 1 set
Combination Machines
Film covering machine 1 set
Slitting machine side waster recoiling machine 1 set
Hydraulic pre-cut (flying shear) 1 set
Bottom panel forming machine 2 sets
Servo pinch feeder mechanical organ 1 set
Rails move and driven system 1 set
Heating system
Double belt system
Flying saw cutting system including control cabinet and servo motor
Panel stacker 1 set
Total electrical cabinet and hydraulic system
Options part: embossing rolls machine, pressing machine and mould, high pressure foam sprayer machine.
Main Technical specifications of continuous polyurethane (PU) sandwich panel Line:
Garage door
: width 435mm--552mm adjustable or according to the customer's requirements
Thickness: 39mm adjustable or according to the customer's requirements
Length: in 1.8m
Note:
We can change the roll forming machine to produce other profiles if customers require.
Wall Panel:
To design according to the customer's requirement
Width: 1000mm
Thickness: 35--200mm adjustable
Length: in 2.5m
Cold room panel:
thickness 80--200mm
Length: according to the customer's requirement
Duct Panel:
width: 120mm or according to the customer's requirement
Thickness: in 20mm
Length: according to the customer's requirement
Line Speed:
3--12m/min (12m/min if overflow case)
Total power:
about 228kw
